Ablative laser resurfacing machine

Treatment: , , , , ,

The ablative laser resurfacing machine laser removes the thin outer layer of skin (epidermis) and heats the underlying skin (dermis), which stimulates the growth of collagen — a protein that improves skin firmness and texture. As the epidermis heals and regrows, the treated area appears smoother and tighter. Types of ablative therapy include a carbon dioxide (CO2) laser, an erbium laser and combination systems. Compare to non-ablative lasers, ablative laser resurfacing machine gives stronger results and long term results.

Ablative fractional carbon dioxide laser resurfacing is a well-established treatment for acne scars. However, there are limited consensus and guidelines regarding the procedure, such as its treatment plan, efficacy, and safety. Ablative fractional carbon dioxide laser is an effective therapy for the treatment of acne scars. The treatment session, interval, and parameters should be customized for each patient. Combination therapy should be considered for ice-pick type acne scars.

  • 10600nm RF tube fractional co2 laser, the medical degrade skin resurfacing technology.
  • RF(radio frequency) tube and glass tube CO2 optional
  • 40W coherent laser, high efficiency
  • Fractional, ultra cutting and vaginal tightening, 3 working modes
  • Long term results and high ROI
  • Unique design, OEM/ODM requirements accepted
  • Professional factory, support selling only kits (without machine case) for foreigner factories

Contact Us
ablative-laser-resurfacing-machine-user-manual Download

We can offer the OEM/ODM services of our products. The product can be customized according to your personalized requirements, including the brand, label, painting colors, and packing box. Please offer your design documents or tell us your ideas and our R&D team will do the rest.

How Does Ablative Laser Resurfacing Machine Works?

Ablative including the 10600nm fractional CO2 laser machines, it using the 10600nm wavelength to target the laser on the skin tissues. During ablative laser resurfacing, an intense beam of light energy (laser) is directed at your skin. The laser beam destroys the outer layer of skin (epidermis). At the same time, the laser heats the underlying skin (dermis), which stimulates collagen production over time, resulting in better skin tone and texture.

Product name Ablative laser resurfacing machine
Technology 10600nm CO2 laser
Display 8.4 inches  true color touch screen
Laser arms Korea import 7 joint laser arms
Wavelength 10600nm
Spot size 0.2mm
Scan area 20mm*20mm
Laser tube RF tube
Power 40W
Voltage 100V-240V, 50Hz/60Hz
Packing size 45cm * 42cm * 56cm
Gross weight 39KG

Spare parts List

NO. SPARE PARTS Quantity (pcs)
1 Host 1
2 Laser arms 1
3 Treatment head 5
4 Switch 2
5 Handles bracket 1
6 Operator goggle 1
8 Patient goggle 1
9 Power supply line 1
10 User manual 1
11 Foot pedal 1
12 Fuse 3
13 “O” type sealing 8
14 Screws 8

Application

  • Ablative laser for Removing acne scars
  • Remove stretch marks
  • Remove fine lines and improve the skin conditions
  • Improve pores and remove pigmentation
  • Vaginal tightening and rejuvenation from inner side to outside

Examples of ablative lasers are CO2 lasers and Erbium YAG lasers. Some non-ablative laser treatments (where the laser passes through the skin without removing layers) cause little-to-no pain and require only a topical numbing cream to offset discomfort.

Your skin usually heals completely in two to four weeks. A new layer of skin covers the wounds after two weeks. In most cases, after about two weeks, patients can use makeup to conceal their skin tone. After the procedures, the skin can remain pink and red for many months afterwards.

Ablative lasers work by removing the outermost layer of skin, helping to deal with issues such as scarring, hyperpigmentation, and skin laxity. By contrast, non-ablative apply stress by heating cells in deeper dermal layers, warming them up to the point where they begin to produce new collagen.

Although not pain-free, ablative laser treatments are generally very well tolerated. We ask that you arrive at least one hour prior to your appointment as this allows us to apply a strong topical numbing cream to the areas being treated.

  1. Redness, swelling, itching and pain. Treated skin may swell, itch or have a burning sensation.
  2. Acne. Applying thick creams and bandages to your face after treatment can worsen acne or cause you to temporarily develop tiny white bumps (milia) on the treated skin.
  3. Infection.
  4. Changes in skin color
  5. Scarring.

The effects of laser skin resurfacing are permanent when it comes to issues such as scarring. Once a specific scar is gone, it will not come back. However, with regard to the visible signs of aging, the results are not permanent
