Bipolar RF machine

Treatment: , , ,

Bipolar RF machine is an advanced and non-invasive procedure for anti-aging and body slimming. Unlike the LASER, the radio frequency (RF) device has no specific chromophore absorption. Thus, the device can be used on any skin type. (This Means RF is safe for dark or black skin).

Although bipolar RF is not as deep as monopolar RF, it has its advantages also. Bi-polar RF treatment does not need any negative plate. Our RF machines offer combined solutions: Mono RF, bipolar RF, and Tripolar RF in one unit. Bipolar RF recommends for superficial layers, Monopolar RF for deeper layers and tripolar RF is more often used for body treatments.

  • 1 pcs handle bipolar RF for fat dissolving, eyes skin lifting and rejuvenation
  • 1 pcs handle 40Khz (5 w/cm2~ 25 w/cm2) Cavitation for deep cellulite reduction.
  • 1 pcs handle Tripolar RF for fat dissolving, facial skin lifting and rejuvenation
  • 1 pcs handle 6 polar RF for body fat dissolving, body sculpturing and de-toxin.
  • Friendly software design for end users.
  • Non-surgical and non-invasive wrinkle removal and fat reduction treatment.
  • Safe, effective and long-term results.
  • Selectively targeting fatty tissues, to avoid any damage to the normal tissues.
  • Unique design, OEM/ODM requirements accepted.
  • Professional factory, support selling only kits (without machine case) for foreign factories.

Contact Us
bipolar-rf-machine-user-manual Download

We can offer the OEM/ODM services of our products. The product can be customized according to your personalized requirements, including the brand, label, painting colors, and packing box. Please offer your design documents or tell us your ideas and our R&D team will do the rest.

How does Bipolar RF machine works?

Bipoar RF, machine is one type of RF machine. The bipolar RF delivers electrical current between the two electrodes applied to the skin. The bipolar type penetrates a smaller volume of tissues, and this allows it to work with even less energy compared to the monopolar type. The depth of heating depends on the size and geometry of the treatment tip. For the bipolar type, the depth is half of the distance between the two electrodes. This gives the monopolar type being able to penetrate deeper, but the bipolar type is still superior in terms of the pain it causes.

Product name Bipolar RF machine
RF Power 300W
Ultrasonic 40Khz
Display 8.4 TFT true color touch screen
RF Frequency 5MHZ
Treatment heads 4 heads
Fuse 5A
Cooling system Air cooling
RF type Mono-polar + Bi-polar + Tripolar + Multipolar
Voltage 100V-240V, 50Hz/60Hz
Packing size 47cm * 39cm * 31cm
Gross weight 11KG

Spare parts List

NO. SPARE PARTS Quantity (pcs)
1 Host 1
2 Handles 4
3 Negative plate 1
4 Switch 2
5 Handles bracket 4
6 Handle plate Optional
7 Power supply line 1
8 Fuse 3
9 “O” type sealing 8
10 Screws 8

Application

  • Tightening sagging or loose skin
  • Reduction of fat accumulation under dermis
  • Lifting face to a V-shaped face
  • Cellulite reduction and skin contouring
  • Improving skin tone
  • Promoting collagen production

Bipolar radiofrequency (RF) utilizes symmetric and closely placed electrodes to pass RF current. through a defined volume of tissue. The approach has benefits over monopolar and unipolar RF in. its control. To optimize these, the electrodes and the RF parameters must be designed and operated.

Monopolar means going through all skin layers, while bipolar/multipolar means staying largely on the surface. In nature, electrical current (or any other energy potential differential) will choose the easiest/shortest possible distance to travel.

It works wonders on the face, too. Radiofrequency face slimming is a favorite among people who want to enhance their appearance without going under the knife, with its proven ability to non-invasively contour the face and create toned, firm, and youthful-looking skin.

HIFU and RF penetrate different layers. Although each individual treatment will produce effective skin tightening results on its own,u00a0they can be combined to target the different layers of skin at different depths. For example, you could choose to do HIFU first, then an RF treatment at a later date.

After your treatment, you should avoid putting foreign products onto your skin. This includes AHA, retinol, vitamin C, and makeup for one week. Furthermore, you should avoid any chemical peels, facial waxing, facials, or other facial treatments for two weeks.
